Ciena 3930 Service Delivery Switches & 3931 Weatherproof Carrier Ethernet System
Juniper ACX5048
ACX5000 LINE OF UNIVERSAL METRO
ROUTERS
ACX5048 | ACX5096 | ACX5448
ACX5448-D | ACX5448-M
REDUCING LEADTIMES
COST SAVINGS
LIFETIME WARRANTY
SUSTAINABLE SOLUTIONS
ACX5000 LINE OF UNIVERSAL METRO ROUTERS
The ACX5000 line of Universal
Metro Routers adds operational intelligence to metro environments, giving you the option to deploy packet optical, Metro Ethernet, and IP/MPLS infrastructure. The ACX5000 platforms address multiple service provider use cases, including cable distributed access architectures, residential fiber (including Juniper Unified PON), and mobile backhaul, as well as enterprise applications for utilities, oil and gas, mining, transportation, defense, and public safety industries.
Features & Benefits of Juniper ACX5000 Series
The ACX Series delivers new levels of programmability, reliability, and scalability to service provider and enterprise networks. The ACX Series portfolio improves customer satisfaction while lowering the total cost of operating, maintaining, and updating the network infrastructure.
1
Zero Touch Deployment
2
Advanced Security Services
3
High Availability and Reliability
4
MEF CE 2.0 Compliant
5
Full Feature Set of L2, L3, IP/MPLS
ACX5000 LINE OF UNIVERSAL METRO ROUTERS
The Juniper Networks® ACX5000 line of Universal Metro Routers is a response to a shift in metro network architectures where the access and aggregation layers are extending operational intelligence from the service provider edge to the access network. The ACX5000 line simplifies access and aggregation architectures by eliminating unnecessary layers and network overlays, dramatically reducing CapEx and OpEx. Based on architectural simplification and cost reduction, the ACX5000 line gives service providers and enterprises the ability to adopt a true universal metro paradigm. The ACX5000 line also provides high capacity, scalability, and a packet optical transport layer, while delivering industry-leading performance with a wide range of port densities and interface types. Table 1 provides an overview of the interfaces supported on each ACX5000 model.
ACX5048
The ACX5048 provides full duplex throughput of 1.44 Tbps in a 1 U platform. Built to handle 1GbE/10GbE capacity and density, it supports 48 1GbE/ 10GbE and six 40GbE interfaces, making it ideal for Metro Ethernet access and aggregation deployments with full support of E-Line, E-LAN, E-Tree, and E-Access, as well as IP/IP VPN services.
ACX5096
The ACX5048 provides full duplex throughput of 1.44 Tbps in a 1 U platform. Built to handle 1GbE/10GbE capacity and density, it supports 48 1GbE/ 10GbE and six 40GbE interfaces, making it ideal for Metro Ethernet access and aggregation deployments with full support of E-Line, E-LAN, E-Tree, and E-Access, as well as IP/IP VPN services.
ACX5448
The ACX5448 offers 48 1GbE/10GbE aggregation ports, four high capacity 40GbE/100GbE uplink ports, and full Metro Ethernet and IP/MPLS VPN services in a space- and cost-optimized platform, smoothing the transition from 10GbE to 100GbE for service providers preparing for the emerging 5G rollout. The ACX5448 supports Juniper’s Unified PON technology.
ACX5448-D
The ACX5448-D supports 36 1GbE/10GbE, two 40GbE/100GbE, and two 100G/200G dense wavelength-division multiplexing (DWDM) ports using CFP2- DCO. It is designed for packet-optical convergence to reduce TCO and to help service providers prepare for the emerging 5G rollout. The ACX5448-D supports Juniper’s Unified PON technology.
ACX5448-M
The ACX5448-M supports 44 1GbE/10GbE and six 40GbE/100GbE ports, as well as advanced security capabilities such as Media Access Control Security (MACsec) on all 1GbE/10GbE ports. The ACX5448-M supports Juniper’s Unified PON technology.
Built-In Interface Options for Various ACX Series Models
| Model | GbE (copper) | GbE (SFP) | 10GbE (SFP+) | 40GbE (QSFP) | 100GbE (QSFP28) | 100/200 Gbps (CFP2-DCO) |
| ACX5048 | 24 (SFP) | 48 | 48* | 6 | – | – |
| ACX5096 | 48 (SFP) | 96 | 96* | 8 | – | – |
| ACX5448 | 48 (SFP) | 48 | 48 | 4 | 4 | – |
| ACX5448-D | 36 (SFP) | 36 | 36 | 2 | 2 | 2 |
| ACX5448-M | 44 (SFP) | 44 | 44 | 6 | 6 | – |
*Small form-factor pluggable plus transceiver (SFP+ transceiver) ports can be configured to be 1GbE ports and accept 1GbE SFP.
Architecture and Key Components
Powered by Juniper Networks Junos® operating system, the ACX5000 line complements Juniper Networks MX Series Universal Routing Platforms through a flexible and scalable service provider and enterprise branch routing portfolio optimized to support rapidly growing mobile, video, and cloud computing applications. The ACX Series introduces Juniper’s proven IP/MPLS leadership from core and edge into the access layers of the network. Maintaining relative simplicity in the access network, the ACX Series supports a rich suite of L2, L3, and IP/MPLS functionality to allow large-scale seamless MPLS networks with simplified service provisioning and operations.
Seamless MPLS: The ACX5000 line of routers supports both
Ethernet bridging and MPLS. Growing demands for bandwidth
are accompanied by network growth in terms of number of
nodes. In some cases, users demand to scale their networks up
to tens of thousands of nodes. Seamless MPLS architecture
enables scale and service flexibility by decoupling physical
topology from transport and service layers. With a seamless
MPLS architecture, service providers can leverage their
existing investment in MPLS in the core and edge and extend
the operational benefit into the access layer. This enables
greater network service flexibility and higher scaling
parameters of the metro area network (MAN), where Metro
Ethernet services can span multiple network segments and be
seamlessly terminated at any point of the network or cloud.
Junos OS: A reliable, high-performance, modular network
operating system, Junos OS is supported across all of Juniper’s
physical and virtual routing, switching, and security platforms.
Junos OS improves network operations and increases service
availability, performance, and security with features like lowlatency
multicast, comprehensive quality of service (QoS),
unified in-service software upgrade (unified ISSU), and Junos
Continuity, which eliminates the risk and complexity of OS
upgrades. Junos OS comes with embedded scripting tools and
APIs, which enable automation of many routine tasks and
practical integration with any operator’s back-end
management tools. With secure programming interfaces, the
Juniper Extension Toolkit (JET), versatile scripting support, and
integration with popular orchestration frameworks, Junos OS
offers flexible options for DevOps-style management that can
unlock more value from the network.
Management: Juniper Networks Junos Space® Network
Management Platform provides comprehensive management
with broad fault, configuration, accounting, performance, and
security management (FCAPS) capabilities for both device and
service-level management. For device management, Junos
Space supports Network Configuration Protocol (NETCONF),
CLI, and SNMP v1/v2/v3, while its northbound APIs support
easy integration with existing network management systems
(NMS) and operations/business support systems (OSS/BSS).
