Calix 100-05529 XG801 Line Cards
E7-2 AXOS XG801
8x XGS-PON/GPON OIM, 4x 10GE SFP+, 2x 100GE QSFP-DD
REDUCING LEADTIMES
COST SAVINGS
LIFETIME WARRANTY
SUSTAINABLE SOLUTIONS
Calix 100-05529 XG801 Line Card
Looking to future-proof your next-generation XGS-PON / GPON network in preparation for launching advanced broadband services? As North America’s most widely deployed access system, the Calix AXOS E7-2 Intelligent Modular System is a breakthrough evolutionary system that provides a transformational path to next generation networks, fiber technologies, and Software Defined Access. The E7-2 is the industry’s benchmark for a modular, small form factor, environmentally hardened access solution for communications service providers (CSPs). Powered by the AXOS platform, the E7-2 is now even more of a disruptive and compelling enabler to next generation networks that connects everyone and everything. The AXOS E7-2 leads a rapidly expanding family of Intelligent Access EDGE systems capable of supporting both centralized and decentralized network architectures that range from the data center edge, central office, or headend, to the remote cabinet, or MDU.
The Calix 100-05529 is an XG801 line card designed for the AXOS E7-2 Intelligent Modular System, offering advanced XGS-PON and GPON capabilities to enhance your network’s performance.
XGS-PON / GPON AND POINT-TO-POINT ETHERNET:
The Calix E7-2 AXOS XG801 card provides multi-service capability over IP/Ethernet-based networks. Each XG801 provides eight selectable XGS-PON / GPON OLT ports that subtend up to 128 ONTs each, for a card capacity of 1,024 PON ONTs, or 2048 per E7-2 1RU chassis. An additional four 10GE SFP+ sockets per card can provide high-bandwidth, point-to-point Ethernet services to individual subscribers or be used to aggregate other Ethernet devices.
Each port can be independently provisioned to support XGS-PON, GPON, or Ethernet connections. The Calix E7-2 XG801 card can co-exist with other Calix E7-2 AXOS line cards in a shelf.
Key Features:
- Versatile Port Configuration: Equipped with eight selectable XGS-PON/GPON OLT ports, each supporting up to 128 Optical Network Terminals (ONTs), allowing for a total capacity of 1,024 ONTs per card.
- High-Speed Connectivity: Includes four 10GE SFP+ sockets for high-bandwidth, point-to-point Ethernet services, and two QSFP-DD ports supporting 100GE uplinks, ensuring robust and scalable network connections.
- Flexible Deployment: Each port can be independently configured to support XGS-PON, GPON, or Ethernet connections, providing adaptability to various network requirements.
G801 card features and capabilities include:
• Based on ITU G.989 XGS-PON family of standards
• XGS-PON: 9.953 Gbps downstream, 9.953 Gbps upstream
• GPON: 2.488 Gbps downstream, 1.244 Gbps upstream
• GEM (Ethernet) based GPON
• Interoperable with Calix ONTs, including GigaFamily and Calix Next Generation 10GPON Residential SFUs, MDUs, and Business ONTs
• Class N1 +29 dB link budget, up to 1:128splits
• Class N2 +31 dB link budget, up to 1:128splits
• Class B+ ODN, +28 dB link budget, up to 20 km at
32- way splits
• Class C+ ODN, +32 dB link budget with Forward Error Correction (FEC), up to 35km at 32-way split, up to 60 km at 2-way split
• Integrated 100GE and 10GE aggregation and transport
• Hardened for central office and remote terminals
Multiple Parts Available & Ready to Ship with Lifetime Warranty
See Part List Below for a Sampling of Our Inventory
Don’t see what you’re looking for? Our Inventory is always changing, please contact us for current stock.
| Manufacturer | Part # | Description | QTY |
| Calix | 100-05529 | E7-2 AXOS XG801 (8x XGS-PON/GPON OIM, 4x 10GE SFP+, 2x 100GE QSFP-DD) | Contact For Current Inventory |
